MAX20303HEWN+T Analog Devices Inc./Maxim Integrated

Manufacturer: Analog Devices Inc./Maxim Integrated
Manufacturer PN: MAX20303HEWN+T
Description: IC BATT PWR MGMT LI-ION 1C 56WLP
Detailed Description: Battery Power Management IC Lithium Ion 56-WLP (4.18x3.68)
Package: 24-PowerQFN
Mfr: NXP USA Inc
Series: -
Switch Type: General Purpose
Number of Outputs: 4
Ratio - Input:Output: 1:1
Output Configuration: High Side
Output Type: N-Channel
Interface: SPI
Voltage - Load: 6V ~ 20V
Voltage - Supply (Vcc/Vdd): 3V ~ 5.5V
Current - Output (Max): 6A
Rds On (Typ): 10mOhm (Max), 35mOhm (Max)
Input Type: -
Features: Internal PWM, Slew Rate Controlled, Watchdog Timer
Fault Protection: Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Operating Temperature: -40°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Supplier Device Package: 24-PQFN (12x12)
Package / Case: 24-PowerQFN
Base Product Number: MC10XS3435
