GAL16V8QS-10LVC National Semiconductor

Manufacturer: National Semiconductor
Manufacturer PN: GAL16V8QS-10LVC
Description: GAL16V8 - LOW VOLTAGE E2CMOS PLD
Detailed Description: GAL®16V8 Programmable Logic Device (PLD) IC 8 Macrocells 20-PLCC (9x9)
Package: 20-VFQFN Exposed Pad
Mfr: Diodes Incorporated
Series: PCI Express® (PCIe)
Applications: PCI Express®
Multiplexer/Demultiplexer Circuit: 2:1
Switch Circuit: -
Number of Channels: 2
On-State Resistance (Max): -
Voltage - Supply, Single (V+): 3V ~ 3.6V
Voltage - Supply, Dual (V±): -
-3db Bandwidth: 8.1GHz
Features: Bi-Directional, SATA, USB 3.0
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 20-VFQFN Exposed Pad
Supplier Device Package: 20-QFN (2.5x4.5)
Base Product Number: PI3PCIE3212
